KND10M (K10M-I) is an economy CNC milling machine controller system, for controlling step motors for 3 axes drilling, boring and milling machines. The control circuit employs hi-speed microprocessor, super-large-scale customized IC chip, multi-layer printed circuit board, and the display is a LCD with high resolution. Hence the whole system is compact, size is greatly reduced, and meanwhile the system reliability is improved further. In term of control software, for the first time the functions of a full-functional CNC system are introduced into the control system of step motor, and many functions applicable for step motor are added, so that its performance is optimized, hence the system has a high cost efficiency.

K10M has the following variations:

K10M I: no switch on the system panel.

K10M II: the system panel has five button switches (Power ON/OFF, Machine Reset, Cycle Start, Feed Hold), Emergency Stop and Override, etc.
