Features

Hi-speed and hi-accuracy control by using a 32-bit processor

The screen is a color/monochrome 7.5² LCD with resolution 640×480.

The main board is a 6-layer circuit board, with surface mount devices (SMD), and customized FPGA, so that it is highly integrated, the whole unit has a reasonable process structure, high interference immunity and reliability.

Full-Chinese operation interface, complete Help info, easy to operate.

Remote control is supported

Employing electronic disk, data will be saved in several positions, can restore rapidly at an error.

Open PLC. Debugging software is provided to meet second development by machine builders. Meanwhile it has built-in standard PLC programs, compatible with K100 series.

Super-strong program command processing capability, up to 10000 pieces/18sec, can achieve hi-speed mini-line cutting.

Hi-speed DNC machining, transmission rate is up to 115200BPS, meanwhile it has program buffer with high capacity.

Program memory with high capacity (640k byte).

With USB interface, supports machining with programs in flash memory stick.

DI/DO can be expanded freely by CAN bus.
